Send InquirySemi Integrated Solar Street Light
Product Details:
- Material street light
- Power 11.1 Watt (w)
- Supply Ability : 1-7 Set Per Day
1200 INR/Piece
X
Price And Quantity
- 1200 INR/Piece
- 500 Set
- 1600.00 - 3200.00 INR/Piece
Product Specifications
- 11.1 Watt (w)
- street light
Trade Information
- 1-7 Set Per Day
- 1 Week
- Yes
- All India
Product Description
Feature
- All in One Solar Street light with provision of AC Mains 230V.
- Smart light having features of Solar and AC street light.
- Reduced backup problem.
- Complete integrated light.
- This smart light comes with all the features of Solar street light & AC street light. It is feeded by SPV & AC mains (230 V). It takes the solar power at priority and charges the battery. In case the battery is in low a condition, then the light is automatically switched to AC mains (230 V). It helps to glow the light during rainy / winter season.
Highlights
Compact Design: Integrated Solar Panel, LED light, Motion sensor, Li-ion/LiFePo4 battery and solar charger controller.
Easy installation: Just unbox the light and tight with the pole with 4nut-bolts and no cable connection.
PIR motion sensor (12M Range): PIR Motion sensor adjusts the brightness of light to extend the backup time.
Li-ion/LiFeP04 battery: Li-ion or LiFeP04 battery provides long life and maintenance free product.
Automatic Dusk to Dawn: Light goes auto off in day time and auto on in night, with activation of motion sensor.
Micro-controller based design: Micro-controller based design provides more efficiency, smartness and more reliability.
Anti-theft: 4M to 5M height provides more protection against theft.
Technical Specifications
| Description | 9W LED | 12W LED | 15W LED | 18W LED |
| Solar Panel | 40 Wp Solar Panel - Poly Crystalline | 50 Wp Solar Panel Poly Crystalline | ||
| Battery Capacity | 11.1V, 11Ah Li-ion 12.8V, 9Ah LiFePo4 | 11.1V, 13Ah Li-ion | 11.1V, 15Ah Li-ion | 11.1V, 19.8Ah Li-ion 12.8V, 18Ah LiFePo4 |
| Lumen Output / Watt | 120 Lumen / Wp | |||
| Operation | Light will glow in full bright mode for first 4Hrs., After 4Hrs. Light will dim to 33% power and motion sensor | |||
| Efficiency | >90% | |||
| light operating voltage | 9.6V - 12.6V | |||
| Battery deep discharge protection Voltage | 9.6V | |||
| Space between light poles | 10M - 15M | 15M - 20M | ||
| Light Backup Time | 2 Days | |||
| Net Weight | 9Kg | 10Kg | 12Kg | 13.5Kg |
| Product Dimension | 72cm x 46cm x 7cm | 66cm x 55.5cm x 7cm | ||
| Protection Provided | Battery deep discharge protection, Over charge Protection, Load Open Protection, Charging and battery | |||
| Packaging contains | Integrated light with SPV, Mounting Bracket, U-clamp, Nut-Bolts. | |||
| Description | 20W LED | 25W LED | 30W LED |
| Solar Panel | 60 Wp Solar Panel | 75 Wp Solar Panel Poly Crystalline | 75 Wp Solar Panel Poly Crystalline |
| Battery Capacity | 11.1V, 23.4Ah Li-ion 12.8V, 21Ah LiFePo4 | 11.1V, 26Ah Li-ion | 11.1V, 32Ah Li-ion |
| Lumen Output / Watt | 120 Lumen / Wp | ||
| Operation | Light will glow in full bright mode for first 4Hrs., After 4Hrs. Light will dim to 33% power and motion sensor will activate for | ||
| Efficiency | >90% | ||
| Light operating voltage | 9.6V - 12.6V | ||
| Battery deep discharge protection Voltage | 9.6V | ||
| Space between light poles | 15M - 20M | 20M - 30M | |
| Light Backup Time | 2 Days | 1.5 Day | |
| Net Weight | 15Kg | 19Kg | 22Kg |
| Product Dimension | 89cm x 50.5cm x 7cm | 101cm x 50 5cm x 7cm | |
| Protection Provided | Battery deep discharge protection, Over charge Protection, Load Open Protection, Charging and battery indication, | ||
| Packaging contains | Integrated light with SPV, Mounting Bracket, U-clamp, Nut-Bolts, Bending Pipe | ||
